Qfieli SS316
azzar li ma jissaddadx ASTM A193 B8M ASTM A194 8M SS316 stud bolt hex bolt washer bolt
azzar li ma jissaddadx ASTM A193 B8M ASTM A194 8M SS316 stud bolt hex bolt washer bolt
1. Dimensjoni SS316
| Qfieli | |||
| Tip | Stud Bolt | Virga bil-kamin | Hex Sokit Kap Vit |
| Eżawrament | U-Bolt | Washer tar-Rebbiegħa | |
| Washer uġigħ | Hex Bolt (ħajta sħiħa, ħajt parzjali) | ||
| Daqs | Stud Bolt | DIN: M6~M100 | ASME: 1/4"~5" |
| Hex Bolt | DIN: M6 ~M64 | ASME: 1/2"~2 1/2" | |
| Temm | Galvanizzazzjoni kiesħa, Hot-dip Galvanizing, PTFE, Zinc Nickel, Kisi iswed, Sempliċi | ||
| Produzzjoni ta' Standard | L-ASME | ASME B18.2.1 | Boltijiet Hex |
| ASME B18.2.2 | Ġewż tal-Eżiti | ||
| ASME B18.22.1 | Washers sempliċi | ||
| Din l-4 | Din931 | Hex Bolt b'ħajt parzjali | |
| Din id-D 933 | Hex Bolt b'ħajta sħiħa | ||
| Din id-D 912 | Hex Sokit Kap Vit | ||
| Din id-D 934 | Eżawrament | ||
| Din id-din 125 | Washer sempliċi | ||
| Din127 | Washer tar-Rebbiegħa | ||
| Din id-din 975 | Vireg bil-kamin | ||
| Din id-din 976 | Boltijiet stud | ||
| DN 3570 | U-Bolt | ||
| Grad materjali | Azzar li ma jissaddadx | 304/304L, 316/316L, 316Ti, 317/317L, 321, 347/347H, 310, 309, A453 660C,660D, S31254/254SMO, 904L/1.4539/N08904, N08367, N08926 / 1.4599/N08904, N08367, N08926 / 1.4599/N08904, N08367, N08926 / 1.459999/N08904, N08367, N08926 / 1.45929/N08904, N08367, N08926 / 1.45929/N08904, N08367, N08926 / 1.45999/N08904, N08367, N08926 / 1.45929/N08904, N08367, N | |
| Azzar Duplex | 2205/S31803, S32750/2507, S32760 | ||
| Azzar liga tan-nikil | UNS N02200/Ni 200, UNS N02201/Ni201, UNS N04400/ Monel 400, UNS N05500/ Monel K500, UNS N06600/ Inconel 600, UNS N06601/ Inconel 601, UNS N06625/ Inconel 625, UNS N08825/ Incoloy 825, UNS N08800/Incoloy 800, UNS N08810 /Incoloy 800H, UNS N08811 /Incoloy 800HT, UNS N08020 /Liga 20, UNS N06002 /Hastelloy X, UNS N06022/ Hastelloy C22, UNS N06200/C2000, UNS N10276/ Hastelloy C276, UNS N10665 /Hastelloy B2, UNS N10675/Hastelloy B3, UNS N08020/ Liga 20, UNS N08031/ Liga 31 | ||
| Azzar tal-Karbonju | Grad 4.8, 5.8, 6.8, 8.8, 10.8, 12.9 | ||
| Azzar liga | A193 B7, A194 2H, A320 L7, L7M | ||
2. Introduzzjoni materjali għall-grad materjali SS316
AZZAR LI MA JISSADDADX 316-316L
316/1.4401/UNS S31600
316L/1.4404/UNS S31603
Kompożizzjoni Kimika
| Ni | Cr | Mo | Mn | Si | C | S | P | N | F' dawn il- | |
| MIN | 10.0 | 16.0 | 2.0 | - | - | - | - | - | - | |
| IL-MASSIMU TA | 14.0 | 18.0 | 3.0 | 2.0 | 0.75 | 0.03 | 0.03 | 0.045 | 0.1 | Bilanċ |
Propjetajiet Fiżiċi
| Temperatura, °F | 70 | 212 | 932 | 1832 |
| Koeffiċjent* tal-Espansjoni Termali, fi/in°F x 10-6 | - | 9.2 | 10.1 | 10.8 |
| Konduttività Termali Btu • ft/ft2 • shr • °F | 7.8 | - | - | - |
| Modulu tal-Elastiċità Dinamika, psi x 106 | 29 | - | - | - |
Densità: 0.285 lb/pulzier3
Proporzjon ta' Poisson: 0.3
Reżistenza elettrika: 445 Ohm-circ mil/ft
Propjetajiet Mekkaniċi
Proprjetajiet rappreżentattivi tensili
| Saħħa Tensili Aħħarija, ksi | 75 |
| 0.2% Qawwa tar-Rendiment, ksi | 30 |
| Titwil, % | 40 |
| Ebusija MAX, Brinell | 217 |
Proprjetajiet Tipiċi tensili u Impatt
| Temperatura, °F | 70 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 |
| Saħħa Tensili Aħħarija, ksi | 82.4 | 75.6 | 71.1 | 71.1 | 71.1 | 68.4 | 50.7 | 30.7 |
| 0.2 % Qawwa tar-Rendiment, ksi | 42.4 | - | - | - | 26.5 | 23.4 | 22.6 | - |
| Impatt Charpy V-notch, ft-lbs | 65 - 100 | - | - | - | - | - | - | - |
3. Ritratt tal-boltijiet tal-istudni SS316
